IV C 900W Dante DSP Network Power Amplifier

Fhbavtec® est Top III Audio System Factory in Sinis. Fhbavtec® IV CH 900W Dante DSP Network Power Amplifier (D4900), cum princeps fidelitate Minimum sonitus XXIV-bit / D et D / A conversionem, quod habet a 3.97-inch tactus LCD screen, Supports IV Danti Signum / IV Analog Signum initus, 900W / c. Fhbavtec® IV CH 900W Dante DSP Network Power Amplifier (D4900) potest facere OEM pro Customer, Laser logo, productio volumine pro una exemplar erit 2000pcs per diem. Duce est 15days.

Model:D4900

Mitte Inquisitionem PDF Download

depictio producti

Fhbavtec® IV Ch 900W Dante DSP Network Power Amplifier (D4900) Product Introduction:

Fhbavtec® IV C 900W Dante DSP Network Power Amplifier (D4900) valde vulgaris in foro, cum potens dsp chip, providing USB et RJ45 portubus ad coniungere ad computer, FCC RJ45 sicut CE, Rohs, FCC etc.

Fhbavtec® IV Ch 900W Dante DSP Network Power Amplifier (D4900) Product parametri:

Series	Dante DSP Network Power Amplifier
Exemplar	D4600	D4750	D4900
8Ω Stereo Power	4x600w	4x750w	4x900w
Frequentatio	XX - XX khz, ± 0.3 DB
Maximum initus gradu	XIV Dbu, libratum initus
Maximum output gradu	DBU XIV, libratum output
Thd + n	<0.008% @ 2.2 DBU
Sampling rate	XLVIII khz
Numerus quantiation bits	XXIV frenum
Bagground sonitus	-88 DBU
Input impedimentis	XX KΩ (libratum initus), X kω (unbalanced input)
Output impeditance	C Ω (libratum output), L Ω (Unbalanced output)
Input sensitivity	1.22v
Input commune rejectio Ratio	> 80db
Output iungo	Steakon obstructionum
USB interface	Parameter potestate via TC software operatio
★ network iunctio input tabernaculi	Coniungere in amplifier ad network ut animadverto remotis modularis temperatio
★ Network iunctio output ostium tabernaculi	Iungo ad proximos network initus possessor est plures ampli online operationem
Signum-ad-sonitus Ratio	> 112db
Damping coefficientem	> M @ 8o
Totalis harmonica distortione	<0.1% (20hz-XX khz 1w)
Frequentatio	20Hz-34khz (+ 0 / -0.3DB, 1W / 8Ω)
Refrigerium	Invalless celeritate imperium fan, airflow ex fronte ad tergum
Amplifier tutela modum	Circuit, Circuit Breaker, DC voltage, overheat, overvoltage, RF, ultra-humilis frequency praesidio
Power Supple Specification	Ac voltage 180-240VC (90v 120vac) 50-60Hz
Gratum Size (H * W * L)	88mmx490mmx438mm
Package Size (H * W * L)	155mmx600mm × 550mm
Pondus retia	13.5kg
Crassa pondus	16.5kg

Fhbavtec® IV Ch 900W Dante DSP Network Power Amplifier (D4900) Main Features:

I. Excelsus perficientur Adi DST processus, princeps fidelitatem humilis strepitu XXIV-bit / D et D / a conversionem;

★ 2.Built, in Dante Network Transmission Module, Supporting IV Dante Signum / IV Analog Signum initus, IV coetibus digital potentia amplificare output;

★ III. Provide USB et RJ45 interface et computatrum nexu;

★ IV. Quisque output channel habet VIII segmentis parametri aequationem, frequency division, mora, limiter, lucrum, polarity;

V. Adopt D classis amplior cum princeps efficientiam et altus potestate densitas, perfect praesidium munus (overcurrent, overheat, princeps frequency praesidium);

VI. 3.97 inch tactus screen, Seres et Latina menu operatio, display contentus magis comprehensive et intuitive.

Fhbavtec® IV Ch 900W Dante DSP Network Power Amplifier (D4900) Applications:

DSP Power AMPLIFICITIUM est idoneam ad imperium et inceptum colloquium, parva et medium-amplitudo testimonii locus, auditorium praetorium, parva et medium-amplitudo convivium, remotis Conference Hall, Conference Center, Remote Conference et aliarum loca.
